Laser Cutting Machine with Work Piece Accessibility

Product Category : Laser Cutting & Punching Machinery

Follow Product

Supplier : MC Craftsman Machinery Pvt. Ltd.

Key Features of Laser Cutting Machine with Work Piece Accessibility

Superior patented cross flow resonator for optimal cutting power.
Low cost of ownership.
Excellent processing performance is achieved through constant gas flow and beam quality.
Intelligent assist gas monitoring, resulting in less scrapped parts.
Automatic quick change gas function.

Enquire now

Product Profile of Laser Cutting Machine with Work Piece Accessibility

MC Craftsman Machinery Pvt. Ltd supplies Laser Cutting Machine with Work Piece Accessibility. MC Craftsman Machinery Pvt. Ltd offers electrical discharge machine [EDM] and CO2 laser cutting machine [LASER]. Laser Cutting Machine with Work Piece Accessibility is available with 2000 and 4000W resonator. Laser Cutting Machine with Work Piece Accessibility is available in 4X4, 4X8 and 5X10 tales. It is available in the model name of HV PLUS.

Key Features of Laser Cutting Machine with Work Piece Accessibility

Superior patented cross flow resonator for optimal cutting power.
Low cost of ownership.
Excellent processing performance is achieved through constant gas flow and beam quality.
Intelligent assist gas monitoring, resulting in less scrapped parts.
Automatic quick change gas function.

Product Specification of Laser Cutting Machine with Work Piece Accessibility

Axis Stroke: X-Axis Stroke: 1249.7 + 149.7 (Load/Unlaod), 2499.4 + 5149 (Load/Unlaod), 3098.80 + 149.9 (Load/Unlaod)<br>Y-Axis Stroke: 1249.7, 1249.7, 1549.4<br>Z-axis Stroke: 299.7
Dimensions: 4089.4 x 2227.6x 2301.2mm, 6090.9x 2227.6x 2301.2mm, 7289.8 x 2227.6 x2301.2mm
Electric Motor: Intelligent Smart Servo
Max. Workpiece Weight: 190.4, 375.9(20CF2) / 596.3 (40CFX), 586.3 (20CF2) / 931.7 (40CFX)
Models: Ml1212HV, ML2512HV, ML3015HV
Pallet Changer: NA
Power Requirement: 38 KVA (20CF2) 3ø 208 VAC +5% 60Hz 106 Full Load Amps, 71 KVA (40CFX) 3ø 208 VAC +5% 60Hz 197 Full Load Amps
Rapid Travel: 49987.2 (single axis)
Repeatability: ±0.005 (X, Y axis)
Weight: 7817.8 (20CF2) / 8817.3 (40CFX), 8819.6 (20CF2) / 9819.5 (40CFX), 10823.5 (20CF2) / 11823.4 (40CFX)
Workpiece dimension: 1219 x 1219, 2438.4 x 1219, 3048 x 1524
