Product Profile of Torque Rheometer For Mixers And Extruders
Toshniwal Brothers [SR] Pvt. Ltd. supplies Torque Rheometer for Mixers and Extruders. Toshniwal Brothers [SR] Pvt. Ltd. offers Industrial Process Equipments, Compressors, High Pressure, and Testing Equipment. The Torque Rheometer for Mixers and Extruders is applied for application investigations in laboratories and simulation. With its digital 3.8-kW motor, a torque measuring range of 200 Nm, and a speed range from 0.2 to 150 min-1.
The Torque Rheometer for Mixers and Extruders is the perfect measuring drive for practice-oriented measurements with the mixers and extruders for:
Raw material and recipe development
Material testing
Quality control parallel to production
Optimization of the production process
Laboratory-scale production of samples for further investigations
Technical specifications of Torque Rheometer for Mixers and Extruders are:
Dynamometer: AC inverter motor, carried in a pendulum bearing
Power: 3.8 kW
Speed: 0.2 - 150 min-1
Speed constancy: quartz precision through digital feedback
Torque measurement: electronically
Torque measuring range: 0 - 200 Nm
Accuracy: better than +/- 0.5% of the selected measuring range
Sense of rotation: forward
Mains: 3 x 400V, 50/60 Hz, +N +PE
Optional: 3 x 200V, 50/60 Hz, +PE, 32 A without transformer
Dimensions [W X H X D] Table-top unit without support: 630 X 450 X 1100 mm
Weight without support: approx. 150 kg
