Rotary Dryers with 5mm Mild Steel Plate

Product Category : Dryers, Rotary

Follow Product

Enquire now

Product Profile of Rotary Dryers with 5mm Mild Steel Plate

Laxmi EN-Fab manufactures Rotary Dryers with 5mm Mild Steel Plate. Laxmi EN-Fab supplies pulverizers & grinding machines. Rotary Dryers with 5mm Mild Steel Plate is available in 30 feet length with zeketed galvanize sheet. Rotary Dryers with 5mm Mild Steel Plate is provided with 24" inch inside plate. The feeding system of this rotary dryer is 10" Inch U bend open screw which is available with gear and motor. The blower of this rotary dryer is 1 Hp for dust collector.

Product Specification of Rotary Dryers with 5mm Mild Steel Plate

Blower: 1 (Dust collector)
Contraction: MS 5 (ms steel plate)
Cyclone: MS without cotton bag
Total Length: 30 length with zeketed Galvanize Sheet
Electric Motor: 3HP 1440 RPM DC Drive (extra cost ) [for Dryer]<br>2 HP 1440 RPM A/C Drive (for screw)
Feeding System: 10" Inch U bend open screw with Gear and motor
Gear Box: 4" Center 30:1 Reito Shricon Brand (for Dryer)<br>3" Inch center 30:1 Reito Shricon Brand (for screw)
Total dia.: 24" Inch inside plate
