Product Profile of Oil Test Set
The Oil Test Set is an equipment-designed and produced to test the electrical strength of Liquid Insulating Materials such as Transformer Oil, Capacitor Oil etc. The test set carries out test on these materials as per Indian Standard Specification IS 6792. R.R. Enterprises is manufacturing Oil Test Set.
R.R. Enterprises offers wide ranges of measuring instruments and high voltage test equipments. The Oil Test Set is essential for Transformer & Switchgear Manufacturers, also for oil filtration units.
Technical Specifications of the Oil Test Set are:
Input: 230/240 Volts 1 Ph 50 Hz AC
Output: 0-60 kV or 0-75 kV or 0-80 Kv or 0-100 kV Center Tap Earthed ? Motorised & Manual Models Available
Capacity: 1 KVA
Indicating: Mains `ON` & `HT ON` Lamps
Metering: 96 sq. mm back of panel mounting, moving coil rectifier type AC Voltmeter to monitor output Voltage
Test to IS 6792, IEC -156
Ergonomic Design Complete User Friendly
Resin Encapsulated HT Transformer
Transparent High Impact Methyl Mathacrylate [ACRYLIC] Test Cup
Removable Mushroom Head Electrode [IS: 6792 & IEC: 156]
Duly Hardened Alloy Steel GO & NO GO gauge
Motorised /Manual OR Motorised cum Manual Operation
Unit Housed in Portable Air Cooled Metal Casing.
