Product Profile of Multiple Circuit Tuned Filter
Multiple Circuit Tuned Filter is designed to operate at different tuning frequencies depending on the presence of them in the network. The Tuned Filter is matched to the environment of the power supply system considering the effect of multiple converters on the network voltage and current distortion factors. The Tuned Filter is assembled in a modular construction from which a number of modules can be assembled to suit the application concerned. The Multiple Circuit Tuned Filter comprises of reactors and capacitors in a series resonant circuit.
Power Matrix Solutions Pvt. Ltd. supplies Multiple Circuit Tuned Filter. Power Matrix Solutions Pvt. Ltd. offers a variety of solutions ranging from power consumption/ compensation to off setting harmful effects of new age electrical polluting devices. The range of products include power conditioning system, power compensation unit, reactive compensation system, capacitor, Tuned Filter, harmonic filter etc.
Key Features of Multiple Circuit Tuned Filter
- The tuning frequency of the filter is made to be equal with the harmonic frequencies generated by the converter loads such as normally the 5th, 7th, 11th and 13th harmonics
- Designed for each of the prominent harmonic frequencies to offer a high level of filtering
- Designed to operate at different tuning frequencies depending on the presence of them in the network
- Matched to the environment of the power supply system considering the effect of multiple converters on the network voltage and current distortion factors
- Assembled in a modular construction from which a number of modules can be assembled to suit the application concerned
- Comprises of reactors and capacitors in a series resonant circuit
