Product Profile of Induction Heater with 11 - 13 kVA Power
Inventum Engineering Company Pvt. Ltd manufactures Induction Heater with 11 - 13 kVA Power. Inventum Engineering Company Pvt. Ltd offers Induction Heaters, Bearing with Plastic Cages, Gears Pinions, Couplings, Pulleys, Fly Wheels, Oil Injection Equipment, etc. The Induction Heater with 11 - 13 kVA Power is a heavy-weight heater of model HIB-03, which are microprocessor based. It weights about 85kg and is thus not practical to be carried around. Hence it is recommended to be placed on a Special Equipment Trolley. The Induction Heater with 11 - 13 kVA Power can heat a bearing of 40 kg to 110 Deg C in about 4 minutes. The Induction Heater with 11 - 13 kVA Power is provided with Roll-sliding Arrangement for the standard yoke 80X80X490 mm. The Roll-Sliding Arrangement is so designed that the yoke gets lifted mechanically and rolls off from the vertical supports, without rubbing or damaging and scraping mating surfaces. This arrangement provides additional safety, ease of operation and helps improve productivity.
Technical Specifications of Induction Heater with 11 - 13 kVA Power are:
Model name: HIB-03
Power: 11 - 13 kVA
Nominal Current: 28-30 A
Residual Magnetism: < 2 A/cm
Space between Vertical Supports [W X H]: 310 X 185mm
Overall Dimensions [W X D X H]: 610 X 320 X 410mm
Weight [Main unit only]: 87 Kgs
Mobility: Special Equipment Trolley
Weight of Components/Bearings: 120 Kgs
