Product Profile of Fuse Holders With Panel Mounting
Elcom International Pvt. Ltd. offers Fuse Holders with Panel Mounting. Elcom International Pvt. Ltd. is an ISO 9001-2000 certified company. Elcom International Pvt. Ltd. supplies various types of Switches, Power Entry Component, Power Cords, Fuse Holders, Connectors, Terminals, Plugs and Sockets, Lamp Holders, Knobs, RFI / EMI Filters, Power Conditioners, Solenoid Connectors and other accessories. The Fuse Holders with Panel Mounting are used for various industrial purposes.
Key Features of Fuse Holders With Panel Mounting
- Mounting Style: Panel
- Permissible Temp. With / Without load: -20 deg C to +85 Deg. C
- Permissible Temp. For Soldering: 270 Deg. C for 5 seconds max.
- Panel Thickness [Max]: 3.0 mm max.
- Material: Polyamide G.F..
- Insulation Resistance: 1000 M Ohms min.
- H. V. Break Down: 2 KV/AC for 1 Minute.
- Current Carrying Parts: Brass, Tin Plated
- Contact Resistance [Initial]: 10 m Ohms max. [Initial]
- Cap Design: Screw-In With Coin Slot
- App. Weight[Gm]: 4.1
- Fuse Link Size: 5 x 20 mm
- Rated Current / Voltage: 6.3 Amps, 250V AC
- Terminals: Solder-type
