Product Profile of Differential Probe With < 1.0 Ghz Bandwidth
Tektronix [India] Private Limited supplies Differential Probe with < 1.0 GHz Bandwidth. The products of Tektronix [India] Private Limited are manufactured according to ISO 9001 certification. The Differential Probe with < 1.0 GHz Bandwidth enable users to make time domain or frequency domain measurements on high bandwidth signals commonly found in disk drive, digital IC design [RAMBUS] and communication applications.
Key Features of Differential Probe With < 1.0 Ghz Bandwidth
- Low Input Capacitance: <1 pF Differential
- Probe Input Connector: Two Standard 0.025 in./0.63 mm [0.1 in. center] Square Pin Receptacle [Female]
- Electrostatic Discharge Tolerant [IEC 801-2]
- Connects to TEKPROBE™ BNC Interface on TDS Series Oscilloscopes or Other Instruments Using 1103 TEKPROBE ®Power Supply
- For Use with Oscilloscopes, Spectrum or Network Analyzers
- >60 dB [1000:1] Common Mode Rejection Ratio [CMRR]
- Small Probe Head Allows Easy Probing of SMDs
- Communications [Gigabit Ethernet, IEEE-1394, Fibre Channel]
- Semiconductor Characterization [RAMBUS]
- Disk Drive Read Channel Design
- Communication Pulse Shape Compliance
- Jitter, Cross-Talk, BERT Measurements
- Location of Ground Bounce
