Product Profile of D.C. Regulated Power Supplies
KB Power Care Pvt. Ltd. manufactures D.C. Regulated Power Supplies. KB Power Care Pvt. Ltd. offers various types of power electronic equipment in industrial applications of the industry.
The D.C. Regulated Power Supplies come with the following specifications:
Input: 230V AC + 10%, 50 Hz, Single Phase
Output: Continuously voltage Variable between 0 - 30 V to 0 -60 V DC
Current variable between 0 - 1A to 0 - 30A
Load Regulation: + 0.1% of the highest specified voltage or better
Line Regulation: + 0.1% + 3m V for + 10% variation in mains input
Ripple: Less than 2 m V rms
Protections: a. Protected against short circuit b. Current limit is set by CURRENT Control / Knob
Recovery Time: Less than 100 micro sec.
Panel Controls
Mains On: Switch to connect the instrument to mains
Voltage Coarse: Adjusts the output voltage by 28/56 Volts
Voltage Fine: Adjusts the output voltage by 2/4 Volts
Current Limit: Adjusts current limit to maximum
