Product Profile of Cable With Stranded Tinned Copper Drain Wire
General Cable offers Cable with Stranded Tinned Copper Drain Wire. All the products of General Cable are manufactured in accordance to ISO 9001:2000. This Cable with Stranded Tinned Copper Drain Wire is of type UL 2919, NEC Type CM [UL] c[UL] CMH. It includes 24 AWG fully annealed stranded tinned copper conductor in twisted pairs. Insulation is of premium-grade, color-coded polyethylene and Shield: 100% Flexfoil ® aluminum/polyester with 25% overlap, minimum, foil facing out. Jacket is PVC, gray with temperature that ranges from -20°C to +80°C.
Applications of Cable with Stranded Tinned Copper Drain Wire include:
Computers
Industrial equipment
Data transmission
Control circuits
Low capacitance requirements
Suitable for EIA RS-232 applications
Suitable for EIA RS-422 applications
Suggested voltage rating: 30 volts
Cable with Stranded Tinned Copper Drain Wire features braid shield which provides good flexibility and there is superior shielding where noise rejection is critical. The cable also assists system designers in meeting FCC Docket 20789 demands.
