Product Profile of Brinell Hardness Testing Machine
Fasne Test Equipment Pvt. Ltd. manufactures Brinell Hardness Testing Machine. Fasne Test Equipment Pvt. Ltd. offers Electronic Extensometer, Boss Microscope with software -for finding out Brinell Hardness value, Brinell Hardness Testing Machine, Optical Brinell Hardness Testing Machine, Pendulum Impact Testing Machine, Dynamic Hardness Testers, etc. The Brinell Hardness Testing Machine of Model AKB-3000 is designed for Brinell hardness measurement on steel & other ferrous materials & also on non-ferrous materials like Brass, Bronze, Aluminum, etc. The material can be cast, forged or rolled & the shape can be flat, round or irregular. The Brinell Hardness Testing Machine is specially used in production testing. Its stability & unique design of a floating fulcrum lever system ensure high accuracy & dependability. The load application system is of dead weight type combined with mechanical lever system. The supporting hydraulic system is for initial lifting of load before each test & damping the load application system for smooth application of load.
Key Features of Brinell Hardness Testing Machine
- Test loads from 500 to 3000 kgf in steps of 250kgf.
- The height X Throat is 380 X 200 mm.
- Indentation measurement by Brinell Microscope of 25 X Magnification.
- Special Test fixtures for odd jobs / production testing can be supplied [Optional]
- Computerized Brinell Impression measurement system is available [Optional]
- Manual / Optical / Computerized type Brinell hardness testing machines are also available.
- Accuracy conforms to IS: 2281-2005 & BS: 240.
