Product Profile of Astro Time Switch
Astro Time Switch is available in a dimension of 160mm [L] X 110mm [W] X 80mm [H]. The Astro Time Switch is featured with 16 x 2 character, wide angle alphanumeric backlit liquid crystal display panel and has two different modes of time and calendar display which is user selectable.
The Astro Time Switch, model ASTRO 8031 works on a power supply input of 230 or 240 VAC, 50 Hz and can function in a temperature ranging from 0 Degree C - 50 Degree C.
Micro Controls offers wide range of electronic systems and energy saving equipments such as low cost Time switches, ATM Timers, Street Light Switches, Cooling Tower Controllers, Astro Time switches and School Bell Timer & LED Bulbs.
Technical Specifications of Time Switch with Manual Push Button:
16 x 2 wide angle alphanumeric backlit liquid crystal display panel
Keyboard: 5 x1 Tactile keyboard
Relay Output: 5 Amps at 240 VAC, resistive load.
Time Base: Accurate Quartz Crystal
Memory Backup: Batteryless memory, Life span - 30 years.
Lithium Cell CR2032 back up for Real Time Clock
Manual Operation: Through push button on front panel.
Temperature: operating in 0 Degree C - 50 Degree C. Storage: 70 Degree C
Enclosure and Mounting: Metallic, Wall Mounting.
Dimension: 160 mm [L] X 110 mm [W] X 80 mm [H]
Input: 230/240 VAC, 50 Hz
