Product Profile of 1.5 Kv Isolated Light Emitting Diode Driver
1.5 KV Isolated Light Emitting Diode Driver is available in a size range of 90X43X33 mm. The Light Emitting Diode Driver is available with 3 pin for I/P and 2 pin for O/P connector. The Light Emitting Diode Driver can operate in a temperature range varying from 0 to 50°C and stored in a temperature range of 0 to 70°C. 1.5 KV Isolated Light Emitting Diode Driver is provided with input low voltage and over voltage cut-off.
Key Features of 1.5 Kv Isolated Light Emitting Diode Driver
- Construction: With Enclosure.
- Terminations: 3 pin for i/p and 2 pin for o/p connector.
- Outputs overload Protection [Fold Back].
- Input low voltage and over voltage cut-off.
- Over temperature protection [thermal shutdown].
- Output short circuit protection.
- Efficiency: > 80% at full load.
- Passive Power Factor Correction: > 0.85.
- Isolation: 1.5 KV.
- Size [L X B X H]: 90X43X33 mm.
- Operating Temperature: 0 to 50°C.
- Storage Temperature: 0 to 70°C.
